Rolle Freeze Protected Emergency Safety Shower and Eyewash
The Rolle 8300FP Freeze Protected Emergency Safety Shower and Eyewash is designed to provide dependable emergency decontamination in outdoor and cold-weather environments where conventional emergency equipment may be at risk of freezing. Engineered for industrial facilities, chemical plants, laboratories and hazardous working environments, the unit delivers rapid emergency response for both eye and body flushing.
Manufactured from hot-dipped galvanised steel pipework with a powder-coated cast iron floor flange, the 8300FP offers excellent durability and corrosion resistance for demanding industrial applications. The self-draining shower and eyewash valves automatically remove residual water after use, helping to prevent freezing and ensuring reliable operation in low-temperature conditions.
The advanced showerhead design delivers a uniform distribution of water across the full shower spray pattern, while the anti-surge eyewash heads provide a gentle and controlled flow to assist with effective eye irrigation during emergencies.
Integrated flow controls allow the shower and eyewash to operate simultaneously, providing complete emergency treatment when both eye and body exposure have occurred. The highly visible push plates feature universal graphics for quick identification and operation during emergency situations.
Designed for hazardous environments where exposure to corrosive, harmful or dangerous substances may occur, the Rolle 8300FP provides a robust and reliable emergency safety solution for outdoor and industrial installations.
Key Features
- Freeze protected emergency shower and eyewash
- Self-draining freeze-resistant design
- Simultaneous shower and eyewash operation
- Hot-dipped galvanised steel construction
- Powder-coated cast iron floor flange
- Anti-surge eyewash heads
- Integrated flow controls
- Large emergency activation push plates
- Highly visible operation graphics
- Corrosion resistant construction
- Suitable for outdoor installations
- Designed for hazardous environments
Specifications
- Brand: Rolle
- Model: 8300FP
- Product Type: Freeze Protected Emergency Shower & Eyewash
- Construction: Hot-Dipped Galvanised Steel
- Floor Flange: Powder-Coated Cast Iron
- Shower Flow Rate: 20 GPM (75.7 L/min)
- Eyewash Flow Rate: 1.2 GPM (4.5 L/min)
- Supply Connections: ¾" NPT and 1¼" NPT
- Waste Connection: 1¼" NPT
- Bury Depth Options: 24" or 42"
- Operation: Self-Draining Push Plate Activation
- Compliance: ANSI Z358.1
- Certification: CSA Certified
Ideal Applications
- Chemical plants
- Industrial facilities
- Laboratories
- Manufacturing plants
- Pharmaceutical facilities
- Petrochemical sites
- Water treatment facilities
- Mining operations
- Outdoor hazardous areas
- Processing facilities
Technical Details
- 1-1/4" IPS Schedule 40 hot-dipped galvanized steel pipe
- Powder-coated cast-iron 9" (22.9 cm) diameter floor flange
- AXION® MSR ABS plastic drench shower head
